ams OSRAM EGA2000 Starboard is a PCB adaptor with a module soldered on it. It is used to connect any EGA2000 module to an external power/control unit. The Starboard diameter is 16mm with a thickness of 1.6mm. It has a pad for a pogo pin or soldered leads.
Starboard diameter = 16mm
Starboard thickness= 1.6mm
Pad for pogo pin or soldered leads
VCSEL Cathode and -ve pads on the exposed base
VCSEL Anode and +ve pads on top
ams OSRAM EGA2000 Industrial High Power Flood Illuminators
Composed of a VCSEL die and a micro-lens array (MLA).
