Abracon APARC1807A-SG3 GNSS Patch Antenna

Abracon APARC1807A-SG3 Global Navigation Satellite System (GNSS) Patch Antenna is a multi-band antenna that supports GPS/GLONASS/Galileo/Beidou. This multi-band GNSS patch antenna comes with integrated Low-Noise Amplifiers (LNA) which facilitate low Voltage Standing Wave Ratio (VSWR) across bands. The APARC1807A-SG3 GNSS patch antenna includes GND plane with a cable and IPEX connector. This multi-band patch antenna features RHCP polarization and offers 50Ω impedance. The APARC1807A-SG3 patch antenna is ideal for GNSS, Internet of Things (IoT), M2M, remote technology monitoring, logistics, surveying, and mapping systems.

Features

  • Compact multi-band GNSS patch antenna
  • Supports GPS/GLONASS/Beidou/Galileo
  • Active antenna with integrated LNA
  • Low VSWR across bands
  • GND plane included with cable and IPEX connector

Specifications

  • Operating frequency:
    • 1561.098MHz ± 2.046MHz for Beidou
    • 1575.420MHz ± 1.023MHz for GPS
    • 1602MHZ ± 8MHz for GLONASS
  • RHCP polarization
  • 50Ω impedance
  • 18mm x 18mm x 7.6mm dimensions

Applications

  • GPS/GLONASS/Galileo/Beidou
  • IoT
  • M2M
  • Remote technology monitoring
  • Geofencing
  • Surveying and mapping systems
  • Logistics

Dimensions (mm)

Mechanical Drawing - Abracon APARC1807A-SG3 GNSS Patch Antenna
